TSI Drum Pump
Model 3/4-B
Simple Operation:
- Thread the pump into the 2" bung
of the 55 Gal. Drum.
- Connect a standard compressed air line.
- Check pump regulated pressure to ensure
it is operating at 4 to 6 Lbs. Psi.
- PUSH THE HANDLE AND WATCH IT FLOW!
Features:
- Simple to use - just hold the
handle and "Watch It Flow"!
- No Cranks, plungers, or levers
to continually compress.
- No Motors (Electric or Air)
- Excellent flow rates
- FM Approved Rigid Brass Safety
Faucet with a Teflon Seal
and "safety lock
out " (standard)
- Uses a LOW operating pressure
- Air Safety Relief Valve to
prevent over-pressure
- One air source can operate Many
Units
- Solid 3/4" Black Pipe
construction (NOT A PLASTIC "TOY")
- Long Lasting - no moving pump
parts
- Two (2) Year Warranty against
manufacturer defects
Average Tested Flow Rates:
Water: 6 - 8 gal. per min.Medium weight Cutting Oil: 2-3 gal.
per min.
Medium Varnish: 2-3 gal. per
min.
*Flow rates will vary
depending on air pressure and viscosity of
liquid.
Weight & Dimensions:
Weight: Approx. 8 Lbs.Length: 44-1/2"
Width: 11"
*For use with chemicals compatible
with
Black Iron, Brass, & Teflon
